AxonOps Agent Installation¶

The AxonOps Agent enables collection of:

Metrics
Logs
Events

The AxonOps Agent also enables the following maintence operations to be performed on the cluster:

Adaptive repairs
Backups

See Installing axon-agent for Cassandra in Docker if you are running Cassandra under Docker.

Version Compatibility¶

AxonOps Agent is available for the following versions of Apache Casssandra and Apache Kafka:

Cassandra¶

Apache Cassandra 3.0.x
Apache Cassandra 3.11.x
Apache Cassandra 4.0.x
Apache Cassandra 4.1.x
Apache Cassandra 5.0.x

Kafka¶

Apache Kafa 2.x
Apache Kafa 3.x

Setup the Package Repository¶

Select the OS Family

Execute the following commands to setup the AxonOps repository:

sudo apt-get update
sudo apt-get install -y curl gnupg ca-certificates

curl -L https://packages.axonops.com/apt/repo-signing-key.gpg \
  | sudo gpg --dearmor -o /usr/share/keyrings/axonops.gpg

echo "deb [arch=arm64,amd64 signed-by=/usr/share/keyrings/axonops.gpg]\
  https://packages.axonops.com/apt axonops-apt main" \
  | sudo tee /etc/apt/sources.list.d/axonops-apt.list
sudo apt-get update

Select Service to Configure¶

Install Cassandra Agent¶

Select the Cassandra Version¶

Select the Java Version¶

Install the AxonOps Cassandra Agent and its dependency axon-agent:

sudo apt-get install axon-cassandra3.0-agent

Configuration File Locations¶

AxonOps Cassandra Agent¶

The AxonOps Cassandra Agent is the jar that is directly loaded by Cassandra. The AxonOps Cassandra Agent then reaches out directly to the AxonOps Agent binary which contacts the AxonOps Server directly.

Configuration File: /etc/axonops/axon-agent.yml
Binary: /usr/share/axonops/axon-cassandra{version}-agent.jar
Version number: /usr/share/axonops/axon-cassandra{version}-agent.version
Copyright: /usr/share/doc/axonops/axon-cassandra{version}-agent/copyright
Licenses: /usr/share/axonops/licenses/axon-cassandra{version}-agent/

AxonOps Agent¶

The AxonOps Agent is a dependency of the AxonOps Cassandra Agent. This binary contacts the AxonOps Server directly while minimizing the memory footprint and CPU utilization of the Cassandra process.

Configuration File: /etc/axonops/axon-agent.yml
Binary: usr/share/axonops/axon-agent
Logs: /var/log/axonops/axon-agent.log
Systemd service: /usr/lib/systemd/system/axon-agent.service

Agent Configuration¶

Update the following lines within /etc/axonops/axon-agent.yml.

The highlighted lines should match the host and org keys found within /etc/axonops/axon-server.yml.

axon-server:
    hosts: "axon-server_endpoint" # Your axon-server IP or hostname, e.g. axonops.mycompany.com
    port: 1888 # The default axon-server port is 1888

axon-agent:
    org: "my-company" # Your organisation name
    # SSL/TLS Settings from AxonOps Agent to AxonOps Server
    tls:
        mode: "disabled" # disabled, TLS
        # Only set below if mode is TLS
        skipVerify: false # Disables CA and Hostname verification
        caFile: "path_to_certs_on_axon_agent_node.crt" # required if skipVerify is not set and you are using a self-signed cert
        certFile: "path_to_certs_on_axon_agent_node.crt"
        keyFile: "path_to_key_file_on_axon_agent_node.key"

NTP:
    host: "ntp.mycompany.com" # Your NTP server IP address or hostname

Ensure Proper Agent Configuration Permissions¶

After editing the file, ensure the file permissions for /etc/axonops/axon-agent.yml are set correctly by running the following commmand:

sudo chmod 0640 /etc/axonops/axon-agent.yml

Configure Cassandra¶

Add the following line at the end of /etc/cassandra/cassandra-env.sh:

JVM_OPTS="$JVM_OPTS -javaagent:/usr/share/axonops/axon-cassandra3.0-agent.jar=/etc/axonops/axon-agent.yml"

If Cassandra was installed using a tarball, the correct path for the cassandra-env.sh will be <Cassandra Installation Directory>/conf/cassandra-env.sh.

NB. Make sure this configuration is not overridden by automation tools.

Configure Cassandra user group¶

Configure the Linux user groups by:

Adding the axonops user to the cassandra user group.
Adding the cassandra user to the axonops user group.

CASSANDRA_GROUP=cassandra
CASSANDRA_USER=cassandra

sudo usermod -aG "$CASSANDRA_GROUP" axonops
sudo usermod -aG axonops "$CASSANDRA_USER"

If Cassandra was setup to use a non-default user or group, CASSANDRA_GROUP and/or CASSANDRA_USER will need be updated accordingly for the above commands to work properly.

Uninstall `needrestart` Package¶

Due to recent change with needrestart, as seen in Ubuntu 24.04, uninstalling the needrestart package is currently recommended.

Failure to uninstall the needrestart package may cause the Cassandra service to be restarted when updating the axon-agent package.

Apply Changes to Cassandra¶

To load the AxonOps Java Agent and Cassandra config changes, run the following command:

sudo systemctl restart cassandra

Install Kafka Agent¶

Select the Kafka Version¶

Install the AxonOps Kafka Agent and its dependency axon-agent:

sudo apt-get install axon-kafka2-agent

sudo apt-get install axon-kafka3-agent

sudo apt-get install axon-kafka2-agent

sudo apt-get install axon-kafka3-agent

Configuration File Locations¶

AxonOps Kafka Agent¶

The AxonOps Kafka Agent is the jar that is directly loaded by Kafka. The AxonOps Kafka Agent then reaches out directly to the AxonOps Agent binary which contacts the AxonOps Server directly.

Configuration File: /etc/axonops/axon-agent.yml
Binary: /usr/share/axonops/axon-kafka{version}-agent.jar
Version number: /usr/share/axonops/axon-kafka{version}-agent.version
Copyright: /usr/share/doc/axonops/axon-kafka{version}-agent/copyright
Licenses: /usr/share/axonops/licenses/axon-kafka{version}-agent/

AxonOps Agent¶

The AxonOps Agent is a dependency of the AxonOps Kafka Agent. This binary contacts the AxonOps Server directly while minimizing the memory footprint and CPU utilization of the Kafka process.

Configuration File: /etc/axonops/axon-agent.yml
Binary: usr/share/axonops/axon-agent
Logs: /var/log/axonops/axon-agent.log
Systemd service: /usr/lib/systemd/system/axon-agent.service

Agent Configuration¶

Update the highlighted lines in /etc/axonops/axon-agent.yml.

These need to match the config that you have in your axon-server.yml setup.

axon-server:
  hosts: "agents.axonops.cloud" # AxonOps SaaS
  # hosts: "${AXONOPS_SERVER_HOSTS}" # AxonOps Server On-Premise Endpoint
  # port: 1888 # AxonOps Server On-Premise Port (Default is 1888)

axon-agent:
  key: "<THIS_IS_A_DUMMY_KEY_PLEASE_UPDATE>"
  org: "<THIS_IS_A_DUMMY_ORG_NAME_PLEASE_UPDATE>"
  cluster_name: "<THIS_IS_A_DUMMY_CLUSTER_NAME_PLEASE_UPDATE>"
  tls:
    mode: "TLS" # disabled, TLS
    #skipVerify: false # Disables CA and Hostname verification
    #caFile: "path_to_certs_on_axon_agent_node.crt" # required if skipVerify is not set and you are using a self-signed cert
    #certFile: "path_to_certs_on_axon_agent_node.crt"
    #keyFile: "path_to_key_file_on_axon_agent_node.key"
# Specify the NTP server IP addresses or hostnames configured for your hosts
# The port defaults to 123 if not specified.
# NTP:
#    hosts:
#        - "x.x.x.x:123"
# Optionally restrict which commands can be executed by axon-agent.
# If "true", only scripts placed in scripts_location can be executed by axon-agent.
# disable_command_exec: false
# If disable_command_exec is true then axon-agent is only allowed to execute scripts
# under this path
# scripts_location: /var/lib/axonops/scripts/

kafka:
  node_type: "broker" # broker, kraft-broker, kraft-controller, zookeeper, connect
  # rack: "testrack" # Auto-detected from Kafka config, optionally override the rack to group nodes in AxonOps
  kafka_client:
    brokers: ["<host_listener_ip_address_or_fqdn>:<port>>"] # 10.0.0.2:9092 or 10.20.30.40:9094 or this_is_my_server.domain.com:9093
    # Authentication Settings
    sasl:
      username: <THIS_IS_A_DUMMY_USERNAME_PLEASE_UPDATE>
      password: <THIS_IS_A_DUMMY_PASSWORD_PLEASE_UPDATE>
      mechanism: PLAIN # SCRAM-SHA-256, SCRAM-SHA-512, OAUTHBEARER, GSSAPI
      # For oauth support
      # oauth:
      #   token:
      #   clientId:
      #   clientSecret:
      #   tokenEndpoint:
      #   scope:
      # For gssapi support
      # gssapi:
      #   authType:
      #   keyTabPath:
      #   kerberosConfigPath:
      #   serviceName:
      #   username:
      #   password:
      #   realm:
      #   enableFast: true
    # SSL settings for connection to Kafka
    tls:
      enabled: true
      caFilepath: <THIS_IS_A_DUMMY_CA_PATH_PLEASE_UPDATE>
      insecureSkipTlsVerify: false

axon-server:
  hosts: "agents.axonops.cloud" # AxonOps SaaS
  # hosts: "${AXONOPS_SERVER_HOSTS}" # AxonOps Server On-Premise Endpoint
  # port: 1888 # AxonOps Server On-Premise Port (Default is 1888)

axon-agent:
  key: "<THIS_IS_A_DUMMY_KEY_PLEASE_UPDATE>"
  org: "<THIS_IS_A_DUMMY_ORG_NAME_PLEASE_UPDATE>"
  cluster_name: "<THIS_IS_A_DUMMY_CLUSTER_NAME_PLEASE_UPDATE>"
  tls:
    mode: "TLS" # disabled, TLS
    #skipVerify: false # Disables CA and Hostname verification
    #caFile: "path_to_certs_on_axon_agent_node.crt" # required if skipVerify is not set and you are using a self-signed cert
    #certFile: "path_to_certs_on_axon_agent_node.crt"
    #keyFile: "path_to_key_file_on_axon_agent_node.key"

# Specify the NTP server IP addresses or hostnames configured for your hosts
# The port defaults to 123 if not specified.
# NTP:
#    hosts:
#        - "x.x.x.x:123"
# Optionally restrict which commands can be executed by axon-agent.
# If "true", only scripts placed in scripts_location can be executed by axon-agent.
# disable_command_exec: false
# If disable_command_exec is true then axon-agent is only allowed to execute scripts
# under this path
# scripts_location: /var/lib/axonops/scripts/

kafka:
  node_type: "zookeeper" # broker, kraft-broker, kraft-controller, zookeeper, connect
  # rack: "testrack" # Optionally specify a rack to group nodes in AxonOps

axon-server:
  hosts: "agents.axonops.cloud" # AxonOps SaaS
  # hosts: "${AXONOPS_SERVER_HOSTS}" # AxonOps Server On-Premise Endpoint
  # port: 1888 # AxonOps Server On-Premise Port (Default is 1888)

axon-agent:
  key: "<THIS_IS_A_DUMMY_KEY_PLEASE_UPDATE>"
  org: "<THIS_IS_A_DUMMY_ORG_NAME_PLEASE_UPDATE>"
  cluster_name: "<THIS_IS_A_DUMMY_CLUSTER_NAME_PLEASE_UPDATE>"
  tls:
    mode: "TLS" # disabled, TLS
    #skipVerify: false # Disables CA and Hostname verification
    #caFile: "path_to_certs_on_axon_agent_node.crt" # required if skipVerify is not set and you are using a self-signed cert
    #certFile: "path_to_certs_on_axon_agent_node.crt"
    #keyFile: "path_to_key_file_on_axon_agent_node.key"

# Specify the NTP server IP addresses or hostnames configured for your hosts
# The port defaults to 123 if not specified.
# NTP:
#    hosts:
#        - "x.x.x.x:123"
# Optionally restrict which commands can be executed by axon-agent.
# If "true", only scripts placed in scripts_location can be executed by axon-agent.
# disable_command_exec: false
# If disable_command_exec is true then axon-agent is only allowed to execute scripts
# under this path
# scripts_location: /var/lib/axonops/scripts/

kafka:
  node_type: "kraft-broker" # broker, kraft-broker, kraft-controller, zookeeper, connect
  # rack: "testrack" # Auto-detected from Kafka config, optionally override the rack to group nodes in AxonOps
  kafka_client:
    brokers: ["<host_listener_ip_address_or_fqdn>:<port>>"] # 10.0.0.2:9092 or 10.20.30.40:9094 or this_is_my_server.domain.com:9093
    # Authentication Settings
    sasl:
      username: <THIS_IS_A_DUMMY_USERNAME_PLEASE_UPDATE>
      password: <THIS_IS_A_DUMMY_PASSWORD_PLEASE_UPDATE>
      mechanism: PLAIN # SCRAM-SHA-256, SCRAM-SHA-512, OAUTHBEARER, GSSAPI
      # For oauth support
      # oauth:
      #   token:
      #   clientId:
      #   clientSecret:
      #   tokenEndpoint:
      #   scope:
      # For gssapi support
      # gssapi:
      #   authType:
      #   keyTabPath:
      #   kerberosConfigPath:
      #   serviceName:
      #   username:
      #   password:
      #   realm:
      #   enableFast: true
    # SSL settings for connection to Kafka
    tls:
      enabled: true
      caFilepath: <THIS_IS_A_DUMMY_CA_PATH_PLEASE_UPDATE>
      insecureSkipTlsVerify: false

axon-server:
  hosts: "agents.axonops.cloud" # AxonOps SaaS
  # hosts: "${AXONOPS_SERVER_HOSTS}" # AxonOps Server On-Premise Endpoint
  # port: 1888 # AxonOps Server On-Premise Port (Default is 1888)

axon-agent:
  key: "<THIS_IS_A_DUMMY_KEY_PLEASE_UPDATE>"
  org: "<THIS_IS_A_DUMMY_ORG_NAME_PLEASE_UPDATE>"
  cluster_name: "<THIS_IS_A_DUMMY_CLUSTER_NAME_PLEASE_UPDATE>"
  tls:
    mode: "TLS" # disabled, TLS
    #skipVerify: false # Disables CA and Hostname verification
    #caFile: "path_to_certs_on_axon_agent_node.crt" # required if skipVerify is not set and you are using a self-signed cert
    #certFile: "path_to_certs_on_axon_agent_node.crt"
    #keyFile: "path_to_key_file_on_axon_agent_node.key"

# Specify the NTP server IP addresses or hostnames configured for your hosts
# The port defaults to 123 if not specified.
# NTP:
#    hosts:
#        - "x.x.x.x:123"
# Optionally restrict which commands can be executed by axon-agent.
# If "true", only scripts placed in scripts_location can be executed by axon-agent.
# disable_command_exec: false
# If disable_command_exec is true then axon-agent is only allowed to execute scripts
# under this path
# scripts_location: /var/lib/axonops/scripts/

kafka:
  node_type: "kraft-controller" # broker, kraft-broker, kraft-controller, zookeeper, connect
  # rack: "testrack" # Auto-detected from Kafka config, optionally override the rack to group nodes in AxonOps
  kafka_client:
    brokers: ["<host_listener_ip_address_or_fqdn>:<port>>"] # 10.0.0.2:9092 or 10.20.30.40:9094 or this_is_my_server.domain.com:9093
    # Authentication Settings
    sasl:
      username: <THIS_IS_A_DUMMY_USERNAME_PLEASE_UPDATE>
      password: <THIS_IS_A_DUMMY_PASSWORD_PLEASE_UPDATE>
      mechanism: PLAIN # SCRAM-SHA-256, SCRAM-SHA-512, OAUTHBEARER, GSSAPI
      # For oauth support
      # oauth:
      #   token:
      #   clientId:
      #   clientSecret:
      #   tokenEndpoint:
      #   scope:
      # For gssapi support
      # gssapi:
      #   authType:
      #   keyTabPath:
      #   kerberosConfigPath:
      #   serviceName:
      #   username:
      #   password:
      #   realm:
      #   enableFast: true
    # SSL settings for connection to Kafka
    tls:
      enabled: true
      caFilepath: <THIS_IS_A_DUMMY_CA_PATH_PLEASE_UPDATE>
      insecureSkipTlsVerify: false

axon-server:
  hosts: "agents.axonops.cloud" # AxonOps SaaS
  # hosts: "${AXONOPS_SERVER_HOSTS}" # AxonOps Server On-Premise Endpoint
  # port: 1888 # AxonOps Server On-Premise Port (Default is 1888)

axon-agent:
  key: "<THIS_IS_A_DUMMY_KEY_PLEASE_UPDATE>"
  org: "<THIS_IS_A_DUMMY_ORG_NAME_PLEASE_UPDATE>"
  cluster_name: "<THIS_IS_A_DUMMY_CLUSTER_NAME_PLEASE_UPDATE>"
  tls:
    mode: "TLS" # disabled, TLS
    #skipVerify: false # Disables CA and Hostname verification
    #caFile: "path_to_certs_on_axon_agent_node.crt" # required if skipVerify is not set and you are using a self-signed cert
    #certFile: "path_to_certs_on_axon_agent_node.crt"
    #keyFile: "path_to_key_file_on_axon_agent_node.key"

# Specify the NTP server IP addresses or hostnames configured for your hosts
# The port defaults to 123 if not specified.
# NTP:
#    hosts:
#        - "x.x.x.x:123"
# Optionally restrict which commands can be executed by axon-agent.
# If "true", only scripts placed in scripts_location can be executed by axon-agent.
# disable_command_exec: false
# If disable_command_exec is true then axon-agent is only allowed to execute scripts
# under this path
# scripts_location: /var/lib/axonops/scripts/

kafka:
  node_type: "connect" # broker, kraft-broker, kraft-controller, zookeeper, connect
  # rack: "testrack" # Optionally specify a rack to group nodes in AxonOps

Set file permissions on /etc/axonops/axon-agent.yml file by executing the following command

sudo chmod 0640 /etc/axonops/axon-agent.yml

Configure Kafka¶

Edit kafka-server-start.sh, usually located in your Kafka install path such as:

/<Kafka_Home>/bin/kafka-server-start.sh

Configure Zookeeper¶

Edit zookeeper-server-start.sh, usually located in your Zookeeper install path such as:

/<Zookeeper_Home>/bin/zookeeper-server-start.sh

Configure KRaft Broker¶

Edit kafka-server-start.sh, usually located in your Kafka install path such as:

/<Kafka_Home>/bin/kafka-server-start.sh

Configure KRaft Controller¶

Edit kafka-server-start.sh, usually located in your Kafka install path such as:

/<Kafka_Home>/bin/kafka-server-start.sh

Configure Connect¶

Edit connect-distributed.sh, usually located in your Kafka install path such as:

/<Kafka_Home>/bin/connect-distributed.sh

Insert the line . /usr/share/axonops/axonops-jvm.options right before the final line in your config file. Look for the last line that starts with exec, as demonstrated in the example below.

NB. Please note the period(.) at the beginning of the config line.

Example:

. /usr/share/axonops/axonops-jvm.options
exec $base_dir/kafka-run-class.sh $EXTRA_ARGS kafka.Kafka "$@"

. /usr/share/axonops/axonops-jvm.options
exec $base_dir/kafka-run-class.sh $EXTRA_ARGS org.apache.zookeeper.server.quorum.QuorumPeerMain "$@"

. /usr/share/axonops/axonops-jvm.options
exec $base_dir/kafka-run-class.sh $EXTRA_ARGS kafka.Kafka "$@"

. /usr/share/axonops/axonops-jvm.options
exec $base_dir/kafka-run-class.sh $EXTRA_ARGS kafka.Kafka "$@"

. /usr/share/axonops/axonops-jvm.options
exec $(dirname $0)/kafka-run-class.sh $EXTRA_ARGS org.apache.kafka.connect.cli.ConnectDistributed "$@"

  EXTRA_ARGS=${EXTRA_ARGS-'-name kafkaServer -loggc -javaagent:/usr/share/axonops/axon-kafka2.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

  EXTRA_ARGS=${EXTRA_ARGS-'-name zookeeper -loggc -javaagent:/usr/share/axonops/axon-kafka2.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

  EXTRA_ARGS=${EXTRA_ARGS-'-name kafkaServer -loggc -javaagent:/usr/share/axonops/axon-kafka2.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

  EXTRA_ARGS=${EXTRA_ARGS-'-name kafkaServer -loggc -javaagent:/usr/share/axonops/axon-kafka2.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

  EXTRA_ARGS=${EXTRA_ARGS-'-name connectDistributed -javaagent:/usr/share/axonops/axon-kafka2.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

. /usr/share/axonops/axonops-jvm.options
exec $base_dir/kafka-run-class.sh $EXTRA_ARGS kafka.Kafka "$@"

. /usr/share/axonops/axonops-jvm.options
exec $base_dir/kafka-run-class.sh $EXTRA_ARGS org.apache.zookeeper.server.quorum.QuorumPeerMain "$@"

. /usr/share/axonops/axonops-jvm.options
exec $base_dir/kafka-run-class.sh $EXTRA_ARGS kafka.Kafka "$@"

. /usr/share/axonops/axonops-jvm.options
exec $base_dir/kafka-run-class.sh $EXTRA_ARGS kafka.Kafka "$@"

. /usr/share/axonops/axonops-jvm.options
exec $(dirname $0)/kafka-run-class.sh $EXTRA_ARGS org.apache.kafka.connect.cli.ConnectDistributed "$@"

  EXTRA_ARGS=${EXTRA_ARGS-'-name kafkaServer -loggc -javaagent:/usr/share/axonops/axon-kafka3.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

  EXTRA_ARGS=${EXTRA_ARGS-'-name zookeeper -loggc -javaagent:/usr/share/axonops/axon-kafka3.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

  EXTRA_ARGS=${EXTRA_ARGS-'-name kafkaServer -loggc -javaagent:/usr/share/axonops/axon-kafka3.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

  EXTRA_ARGS=${EXTRA_ARGS-'-name kafkaServer -loggc -javaagent:/usr/share/axonops/axon-kafka3.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

  EXTRA_ARGS=${EXTRA_ARGS-'-name connectDistributed -javaagent:/usr/share/axonops/axon-kafka3.0-agent.jar=/etc/axonops/axon-agent.yml --add-exports=java.base/sun.nio.ch=ALL-UNNAMED --add-opens=java.base/sun.nio.ch=ALL-UNNAMED --add-exports=jdk.unsupported/sun.misc=ALL-UNNAMED --add-exports=jdk.compiler/com.sun.tools.javac.tree=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.code=ALL-UNNAMED  --add-exports=jdk.compiler/com.sun.tools.javac.util=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.mbeanserver=ALL-UNNAMED --add-opens=java.management/com.sun.jmx.interceptor=ALL-UNNAMED --add-exports=java.management/com.sun.jmx.interceptor=ALL-UNNAMED'}

NB. Make sure that this configuration will not get overridden by an automation tool.

Add axonops user to Kafka user group and Kafka user to axonops group¶

sudo usermod -aG <your_kafka_group> axonops
sudo usermod -aG axonops <your_kafka_user>

Start/Restart Kafka¶

To load the AxonOps Java Agent and Kafka config changes please either start the Kafka service if stopped restart the Kafka service if already running.

Add axonops user to Zookeeper user group and Zookeeper user to axonops group¶

sudo usermod -aG <your_zookeeper_group> axonops
sudo usermod -aG axonops <your_zookeeper_user>

Start/Restart Zookeeper¶

To load the AxonOps Java Agent and Zookeeper config changes please either start the Zookeeper service if stopped or restart the Zookeeper service if already running.

Add axonops user to KRaft Broker user group and KRaft Broker user to axonops group¶

sudo usermod -aG <your_kraft_group> axonops
sudo usermod -aG axonops <your_kraft_user>

Start/Restart KRaft Broker¶

To load the AxonOps Java Agent and Kafka KRaft config changes please either start the Kafka KRaft service if stopped or restart the Kafka KRaft service if already running.

Add axonops user to KRaft Controller user group and KRaft Controller user to axonops group¶

sudo usermod -aG <your_kraft_group> axonops
sudo usermod -aG axonops <your_kraft_user>

Start/Restart KRaft Controller¶

To load the AxonOps Java Agent and Kafka KRaft config changes please either start the Kafka KRaft service if stopped or restart the Kafka KRaft service if already running.

Add axonops user to Kafka Connect user group and Kafka Connect user to axonops group¶

sudo usermod -aG <your_connect_group> axonops
sudo usermod -aG axonops <your_connect_user>

Start/Restart Kafka Connect¶

To load the AxonOps Java Agent and Kafka Connect config changes please either: * Start the Kafka Connect service if stopped. * Restart the Kafka Connect service if already running.

Start the AxonOps Agent¶

sudo systemctl start axon-agent

AxonOps Agent Installation¶

Version Compatibility¶

Cassandra¶

Kafka¶

Setup the Package Repository¶

Select Service to Configure¶

Install Cassandra Agent¶

Select the Cassandra Version¶

Select the Java Version¶

Configuration File Locations¶

AxonOps Cassandra Agent¶

AxonOps Agent¶

Agent Configuration¶

Ensure Proper Agent Configuration Permissions¶

Configure Cassandra¶

Configure Cassandra user group¶

Uninstall needrestart Package¶

Apply Changes to Cassandra¶

Install Kafka Agent¶

Select the Kafka Version¶

Select the Java Version.¶

Configuration File Locations¶

AxonOps Kafka Agent¶

AxonOps Agent¶

Agent Configuration¶

Configure Kafka¶

Configure Zookeeper¶

Configure KRaft Broker¶

Configure KRaft Controller¶

Configure Connect¶

Add axonops user to Kafka user group and Kafka user to axonops group¶

Start/Restart Kafka¶

Add axonops user to Zookeeper user group and Zookeeper user to axonops group¶

Start/Restart Zookeeper¶

Add axonops user to KRaft Broker user group and KRaft Broker user to axonops group¶

Start/Restart KRaft Broker¶

Add axonops user to KRaft Controller user group and KRaft Controller user to axonops group¶

Start/Restart KRaft Controller¶

Add axonops user to Kafka Connect user group and Kafka Connect user to axonops group¶

Start/Restart Kafka Connect¶

Start the AxonOps Agent¶

Uninstall `needrestart` Package¶
